Professional Chain Convey Sliding Line Transfer Cart On Rail
| Menşe yeri | Henan, Çin |
|---|---|
| Marka adı | BEFANBY |
| Sertifika | CE,SGS,ISO9001 |
| Model numarası | KPC |
| Min sipariş miktarı | 1 set/set |
| Fiyat | Anlaşılabilir |
| Ambalaj bilgileri | Transfer arabası muşamba tarafından paketlenecek, parçalar yüksek kaliteli ahşap kasa olarak paketle |
| Teslim süresi | Her zamanki teslimat olarak 20-30 gün |
| Ödeme koşulları | L/C,T/T,Western Union |
| Yetenek temini | Yıllık 1500 set/set |
Ücretsiz numune ve kuponlar için bana ulaşın.
Naber:0086 18588475571
sohbet: 0086 18588475571
Skype: sales10@aixton.com
Herhangi bir endişeniz varsa, 24 saat çevrimiçi yardım sağlıyoruz.
xÜrün ayrıntıları
| Renk | Özelleştirilmiş | Garanti | 24 ay |
|---|---|---|---|
| Yük kapasitesi | Özelleştirilmiş | Güç Kaynağı | Pil çalıştırıldı |
| Liman | Qingdao/Tianjin/Shanghai | Uygulama | Ağır endüstri, dış mekan, inşaat |
| Malzemeler | Çelik |
Ürün Açıklaması
Professional Chain Convey Sliding Line Transfer Cart On Rail
Product Description
In the current manufacturing industry, as production processes gradually move towards intelligent and continuous production, stable and efficient internal transportation systems have become a crucial component of factory competitiveness. Sliding contact line powered rail transport vehicles, with their continuous long-term operation, reliable structural design, and highly automated interface capabilities, are becoming core logistics equipment in semi-automated production workshops.
Company Profile
Support Customized
To adapt to different material characteristics and production line integration requirements, the sliding contact line transporter offers a variety of platform structures:
Chain conveyor platform: accurately adapts to automated lines for automated loading and unloading.
Roller conveyor platform: suitable for the continuous transport of boxes, pallets, and square products.
V-shaped frame, coil frame: used for the stable placement of round materials such as coils, steel coils, and aluminum coils.
Liftable platform: hydraulic or scissor lifting, suitable for connecting workstations at different heights.
The equipment adopts a high-strength frame, wear-resistant and non-slip cast steel wheels, and anti-slip structure, ensuring smooth operation and reducing maintenance frequency.
Product Parameter
| Model | KPX-10t | KPX-16t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
| Rated Load | 10 | 16 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table size | Length(L) | 3600 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Width(W) | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
| Height(H) | 500 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
| Wheel Base | 2600 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Rail Inner Gauage | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel Diameter | 300 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| Running Speed | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
| Motor Power | 2 | 2.2 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | 15 | |
| Battery Capacity | 160 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
| Battery Voltage | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
| Max Wheel Load | 42.6 | 64.5 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| Reference Weight | 4.2 | 5.5 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 | |
Product Feature
Applications
Equipment transportation for oil refineries
Transfer of chemical raw materials and parts
Transport of circular pipe components and high-temperature workpieces
Logistics transportation and warehouse storage
Shipping
Related Products
FAQ
1) Q: How can I operate the transfer cart ?
A: Please don't worry, dear friend. The English user manual, parts manual will be delivered with your items together.
2) Q: How to ensure your product quality ?
A : We will free provide rail installation drawing, rail foundation construction drawing, free technical guide. And if necessary,our installation engineer will go to your factory to guide the installation.
3)Q: Whether you can offer customized transfer car?
A: Yep, of course, we are manufacturer, and we have our own engineer group. They can work out customized design according to your requirement. The most important thing is that you tell us what you need.
4)Q: Whether there is professional technician assist our installation?
A :Yep. We have professional installation team, who have gone to many countries to assist the installation. If you need we send technician to your factory, please let us know in advance. So that we can arrange technicians.
